Name: 425C Dual Pack Platinum (Gen 2)
Brand: Viair
SKU: VA-42513
Price: 422.55 USD
Availability: InStock

Description

BUILT-IN RELIABILITY
1/4 NPT stainless steel braided leader hose
with an inline check valve.

WORKHORSE
Capable of putting out 4.94 CFM at zero PSI head pressure.

FASTER FILLS
Fill your tank from 145 to 175PSI
in just 1 min 05 sec.

VIAIRs brand new 425C Gen. 2 compressor delivers game-changing performance, capable of putting out 4.94 CFM at zero PSI head pressure. The 425C is our first compressor with duty cycle of 33% at 175 PSI and 50% at 100 PSI. The 425C features upgraded internal components that make it a true 175 PSI-rated working pressure pump.

The 425C Dual Performance Value Pack features two 12V 425C compressors with newly-developed sleek head design, increased duty cycle and quieter dB levels. The 425C is available in Platinum or Stealth Black, and comes equipped with a stainless steel braided leader hose with an inline check valve.

Additional Info Download:

Manual

Dimensional Drawing

Wiring Diagram

Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque is 12 to 15 ft. lbs.

Features & Specifications

Performance Data

* Supply Voltage: 13.8 Volts

Fill Rates

FEATURES

(2) 425C Platinum Compressors
w/Thermal Overload Protectors

Stainless Steel Braided Leader Hose with Inline Check Valve

(2) Air Filter Assemblies

(2) VIAIR Removable Filter Covers

(2) Replacement Air Filter Elements

(2) Remote Mount Brackets

(2) Sets of Remote Mount Fittings

Set of Spare Air Filter Elements

(2) Leader Hose Clips

(6) Air Line Clips with Included Hardware

(8) Sets of Nuts, Bolts, Washers, and Lock Washers

(2) Heavy Duty 40-Amp Relays

(1) Heavy Duty Pressure Switch (140 PSI on, 175 PSI off)

Air Line (For Remote Mount Filter Installation)

SPECIFICATIONS

12-Volt

Permanent Magnetic Motor

Duty Cycle: 50% @ 100 PSI

Duty Cycle: 33% @ 175 PSI

Max. Working Pressure: 175 PSI

Max. Air Tank Size: 10.0 Gallon

Combined Max. Amp Draw: 60-Amps

Ingress Protection Rating: IP67

Max Ambient Temp: +158°F

Min Ambient Temp: -40°F

Dimensions: 9.25?L x 3.31?W x 6.59?H

Net Weight: 11.10 lbs.

Please Note: Use thread sealant for proper installation. Thread tape is not recommended.
Properly sealed, recommended torque for 1/8 is 10 ~ 11 ft. lbs. Recommended torque for 1/4 and 3/8 is 16 ~ 18 ft. lbs.

PERFORMANCE DATA

PSI	CFM	A	BAR	LPM	A
0	4.94	36	0	140.0	36
10	4.57	39	1.0	125.8	41
20	4.31	43	2.0	116.7	46
30	4.07	46	3.0	104.2	49
40	3.86	48	4.0	94.2	51
50	3.50	50	5.0	86.3	52
60	3.27	51	6.0	78.7	53
70	3.09	52	7.0	72.5	54
80	2.88	53	8.0	63.3	53
90	2.74	54	9.0	56.3	52
100	2.56	54	10.0	48.3	50
110	2.39	54	11.0	41.8	48
120	2.15	53	12.0	36.7	46
130	1.99	52
140	1.85	51
150	1.62	50
160	1.48	48
170	1.38	47
175	1.29	46

* Supply Voltage: 13.8 Volts

FILL RATES

2.0 GALLON TANK	FILL RATE
0 to 175 PSI	1 min. 20 sec. (± 10 sec.)
140 to 175 PSI	25 sec. (± 05 sec.)
2.5 GALLON TANK	FILL RATE
0 to 175 PSI	1 min. 35 sec. (± 10 sec.)
140 to 175 PSI	30 sec. (± 05 sec.)
5.0 GALLON TANK	FILL RATE
0 to 175 PSI	3 min. 20 sec. (± 10 sec.)
140 to 175 PSI	1 min. 05 sec. (± 05 sec.)
